VENTILATION FAN EAF-4900CMH
Type: Axial ducted in-line
c/w Motor fired rated 300°C in 2 hours
Air flow (CMH): 4900
Pressure (Pa): 420
Pressure at 3m (dB(A)): 73
Voltage (V/Ph/Hz): 380/3/50
Origin: Kruger Vietnam
• Size from 315 to 2000
• Capacity up to 360,000 m3/h
• Static pressure up to 1,000 Pa
• Suitable for clean air normal ventilation and smokespill application.
• Normal Ventilation: -20°C to +55°C
• High Temperature Application: available up to 400°C/2Hrs.
Totally enclosed Class 'F' or 'H', with a minimum IP55 protection are fitted as standard. Standard motor up to 2.2kW are supplied with DOL starting, motor 3.0kW and above are with star/delta starting. Motor of other specifications are available upon request.
